SPDT30G – Low insertion loss DC-30 GHz SPDT switch
[In active production]
Main Features:
- True DC, wideband (0 to 30 GHz)
- Low Insertion loss, (< 0.9 dB up to 30 GHz)
- High linearity (IP3 > 90 dBm)
- High isolation (> 35 dB up to 30 GHz)
- Low Consumption (< 1 µA)
- Compact Flipchip solution (2.8 x 2.3 mm²)
AIR10A – SPST Power switch
Main Features:
- Voltage Type (DC)
- Standoff Voltage (120V)
- Current Rating (10A)
- Contact Resistance (10mΩ)
- Control Voltage (120V)
- Switching Mode (Cold Switching)
- Size (2.8mm x 3.8mm x 1mm 10.6mm³)
AIR500mA – SPST Power switch
Main Features:
- Voltage Type (DC)
- Standoff Voltage (100V)
- Current Rating (500mA)
- Contact Resistance (190mΩ)
- Insertion loss, (-0.05 dB @100 MHz)
- Return loss, (-41 dB @100 MHz)
- Control Voltage (90V)
- Switching Mode (Cold Switching)
- Size (1.7mm x 1.7mm x 1.45mm 4.2mm³)
AIR40SE0 – Low insertion loss DC-40 GHz SPDT switch
Main Features:
- True DC, ultra-wideband (0 to 40 GHz)
- Low Insertion loss, (< 1.26 dB @40 GHz)
- High linearity (IP3 > 60 dBm)
- High isolation (> 32 dB @ 40 GHz)
- Video feedthrough (< 1 mVpp)
- Low Power Consumption (< 1 µW)
- Compact Flipchip solution (2.8 x 2.3 mm²)
